STEERING HEAD
4-59
17 Bearing cover 1
18 Bearing inner race 2
19 Upper bearing 1
20 Lower bearing 1
21 Dust seal 1
22 Bearing outer race 2
For installation, reverse the removal proce-
dure.
Removing the lower bracket
Order Job/Parts to remove Q’ty Remarks
