Yamaha YZF-R1 (2006) [42/426] Tightening torques

TIGHTENING TORQUES

2-13

EAS20340

ENGINE TIGHTENING TORQUES

Item

Threa

d size

Q’ty Tightening torque Remarks

Spark plugs M10 4 13 Nm (1.3 m·kg, 9.4 ft·lb)

Cylinder head nut (2pieces) M10 2 See NOTE

Cylinder head nut (8pieces) M10 8 See NOTE

Cylinder head bolt M6 2 12 Nm (1.2 m·kg, 8.7 ft·lb)

Camshaft cap bolt M6 20 10 Nm (1.0 m·kg, 7.2 ft·lb)

Cylinder head cover bolt M6 6 12 Nm (1.2 m·kg, 8.7 ft·lb)

Cylinder head stud bolt (exhaust

pipe)

M8 8 15 Nm (1.5 m·kg, 11 ft·lb)

Air induction system cap bolt M6 4 10 Nm (1.0 m·kg, 7.2 ft·lb)

Camshaft sprocket bolt M7 4 24 Nm (2.4 m·kg, 17 ft·lb)

Cylinder head and throttle body

clamp

M6 7 10 Nm (1.0 m·kg, 7.2 ft·lb)

Connecting rod cap bolt (1st) M8 8 20 Nm (2.0 m·kg, 14 ft·lb)

Connecting rod cap bolt (final) M8 8 specified angle 150°

Generator rotor bolt M10 1 60 Nm (6.0 m·kg, 43 ft·lb)

Timing chain tensioner bolt M6 2 10 Nm (1.0 m·kg, 7.2 ft·lb)

Water pump outlet pipe bolt M6 1 10 Nm (1.0 m·kg, 7.2 ft·lb)

Water pump inlet pipe bolt (water

pump side)

M6 1 10 Nm (1.0 m·kg, 7.2 ft·lb)

Water pump inlet pipe bolt (front

side)

M6 1 10 Nm (1.0 m·kg, 7.2 ft·lb)

Oil/water pump drive sprocket

bolt

M6 1 15 Nm (1.5 m·kg, 11 ft·lb)

Water pump bolt M6 2 12 Nm (1.2 m·kg, 8.7 ft·lb)

Thermostat cover nut M6 2 10 Nm (1.0 m·kg, 7.2 ft·lb)

Thermostat inlet pipe bolt M6 1 10 Nm (1.0 m·kg, 7.2 ft·lb)

Oil cooler bolt M20 1 63 Nm (6.3 m·kg, 46 ft·lb)

Engine oil drain bolt M14 1 43 Nm (4.3 m·kg, 31 ft·lb)

Oil pipe bolt M6 2 10 Nm (1.0 m·kg, 7.2 ft·lb)

Oil strainer bolt M6 3 10 Nm (1.0 m·kg, 7.2 ft·lb)

Oil delivery pipe bolt M6 3 10 Nm (1.0 m·kg, 7.2 ft·lb)

Oil filter union bolt M20 1 70 Nm (7.0 m·kg, 51 ft·lb)

Oil filter M20 1 17 Nm (1.7 m·kg, 12 ft·lb)

Oil pan bolt M6 14 12 Nm (1.2 m·kg, 8.7 ft·lb)

Air filter case screw M5 9 2.0 Nm (0.2 m·kg, 1.4 ft·lb)

Air filter case and funnel screw M5 2 2.5 Nm (0.25 m·kg, 1.8 ft·lb)

Throttle body and throttle body

joint clamp

M5 4 3.0 Nm (0.3 m·kg, 2.2 ft·lb)

Throttle body and funnel bolt M6 6 6.0 Nm (0.6 m·kg, 4.3 ft·lb)

Throttle cable adjusting bolt M5 2 4.0 Nm (0.4 m·kg, 2.9 ft·lb)

Cylinder head and exhaust pipe

nut

M8 8 20 Nm (2.0 m·kg, 14 ft·lb)
