Yamaha YZF-R1 (2006) [43/426] Tightening torques

TIGHTENING TORQUES

2-14

Exhaust pipe and muffler bolt M8 2 20 Nm (2.0 m·kg, 14 ft·lb)

Exhaust pipe and EXUP valve

bolt

M6 5 12 Nm (1.2 m·kg, 8.7 ft·lb)

Exhaust valve pipe bracket bolt M8 1 20 Nm (2.0 m·kg, 14 ft·lb)

EXUP pulley and shaft arm nut M6 1 6.5 Nm (0.65 m·kg, 4.7 ft·lb)

EXUP valve pulley cover bolt M6 2 10 Nm (1.0 m·kg, 7.2 ft·lb)

EXUP valve and EXUP valve pipe

bolt

M6 1 10 Nm (1.0 m·kg, 7.2 ft·lb)

EXUP cable bracket bolt M6 1 10 Nm (1.0 m·kg, 7.2 ft·lb)

EXUP cable nut M6 2 6.5 Nm (0.65 m·kg, 4.7 ft·lb)

EXUP servo motor cover bolt M5 2 2 Nm (0.2 m·kg, 1.4 ft·lb)

EXUP servo motor bolt M6 2 6.0 Nm (0.6 m·kg, 4.3 ft·lb)

Catalyst pipe bracket and rear

frame

M8 1 20 Nm (2.0 m·kg, 14 ft·lb)

Catalyst pipe and EXUP valve

pipe bolt

M8 1 20 Nm (2.0 m·kg, 14 ft·lb)

Catalyst pipe and catalyst pipe

bracket bolt

M8 1 20 Nm (2.0 m·kg, 14 ft·lb)

Catalyst pipe protector M6 4 6.5 Nm (0.65 m·kg, 4.7 ft·lb)

Muffler and rear frame bolt M8 2 23 Nm (2.3 m·kg, 17 ft·lb)

Muffler protector bolt M6 4 10 Nm (1.0 m·kg, 7.2 ft·lb)

Crankcase stud bolt M10 10 8.0 Nm (0.8 m·kg, 5.8 ft·lb)

Crankcase bolt (main journal) M9 10 See NOTE

Crankcase bolt M6 2 10 Nm (1.0 m·kg, 7.2 ft·lb)

Crankcase bolt M6 8 10 Nm (1.0 m·kg, 7.2 ft·lb)

Crankcase bolt M8 1 24 Nm (2.4 m·kg, 17 ft·lb)

Crankcase bolt M8 5 24 Nm (2.4 m·kg, 17 ft·lb)

Generator rotor cover bolt M6 4 12 Nm (1.2 m·kg, 8.7 ft·lb)

Generator rotor cover bolt M8 3 22 Nm (2.2 m·kg, 16 ft·lb)

Drive sprocket cover bolt M6 3 12 Nm (1.2 m·kg, 8.7 ft·lb)

Crankcase cover bolt M6 3 10 Nm (1.0 m·kg, 7.2 ft·lb)

Clutch cover bolt M6 7 12 Nm (1.2 m·kg, 8.7 ft·lb)

Clutch cover bolt M6 1 12 Nm (1.2 m·kg, 8.7 ft·lb)

Pickup rotor cover bolt M6 6 12 Nm (1.2 m·kg, 8.7 ft·lb)

Breather cover bolt M6 4 12 Nm (1.2 m·kg, 8.7 ft·lb)

Breather plate bolt M6 3 10 Nm (1.0 m·kg, 7.2 ft·lb)

Plate bolt M6 1 12 Nm (1.2 m·kg, 8.7 ft·lb)

Pickup rotor cover blind bolt M8 1 15 Nm (1.5 m·kg, 11 ft·lb)

Oil level plug M20 1 1.5 Nm (0.15 m·kg, 1.1 ft·lb)

Generator rotor cover plug M20 1 8.0 Nm (0.8 m·kg, 5.8 ft·lb)

Main gallery plug (oil return) M16 3 8.0 Nm (0.8 m·kg, 5.8 ft·lb)

Main gallery plug M20 1 8.0 Nm (0.8 m·kg, 5.8 ft·lb)

Item

Threa

d size

Q’ty Tightening torque Remarks
