ENGINE SPECIFICATIONS
2-7
Secondary reduction ratio 45/17 (2.647)
Operation Left foot operation
Gear ratio
1st 38/15 (2.533)
2nd 33/16 (2.063)
3rd 37/21 (1.762)
4th 35/23 (1.522)
5th 30/22 (1.364)
6th 33/26 (1.269)
Main axle runout limit 0.08 mm (0.0032 in)
Drive axle runout limit 0.08 mm (0.0032 in)
Shifting mechanism
Shift mechanism type Shift drum and guide bar
Shift fork guide bar bending limit 0.100 mm (0.0039 in)
Shift fork thickness 5.80–5.88 mm (0.2283–0.2315 in)
Air filter
Air filter element Oil-coated paper element
Fuel pump
Pump type Electrical
Model/manufacturer 4C8/DENSO
Maximum consumption amperage 6.0 A
Output pressure 324.0 kPa (46.1 psi) (3.24 kgf/cm²)
Fuel injector
Model/quantity 297500-1110/4
Manufacturer DENSO
Throttle body
Type/quantity 45EIDW/1
Manufacturer MIKUNI
ID mark 4C81 00 (U.S.A.)
4C85 10 (California)
Throttle valve size #50
Throttle position sensor
Resistance 2.0–3.0 kΩ
Output voltage (at idle) 0.63–0.73 V
Idling condition
Engine idling speed 1150–1250 r/min
Intake vacuum 22.0 kPa (6.5 inHg) (165 mmHg)
Water temperature 95.0–105.0 °C (203.00–221.00 °F)
Oil temperature 80.0–90.0 °C (176.00–194.00 °F)
Throttle cable free play 3.0–5.0 mm (0.12–0.20 in)
