PERIODIC MAINTENANCE
3-2
4 * Rear brake
• Check operation, fluid level,
and for fluid leakage.
• Replace brake pads if neces-
sary.
√√√√√√
5 * Brake hoses
• Check for cracks or damage. √√√√√
• Replace. Every 4 years
6 * Wheels
• Check runout and for damage.
• Replace if necessary.
√√√√√
7*Tires
• Check tread depth and for
damage.
• Replace if necessary.
• Check air pressure.
• Correct if necessary.
√√√√√
8 * Wheel bearings
• Check bearings for smooth
operation.
• Replace if necessary.
√√√√√
9*
Swingarm pivot
bearings
• Check bearing assemblies for
looseness.
• Moderately repack with lithium
soap-based grease.
√ Repack.
10 Drive chain
• Check chain slack, alignment
and condition.
• Adjust and lubricate chain with
a special O-ring chain lubricant
thoroughly.
Every 500 mi (800 km) and after washing the vehicle or riding in the rain
11 * Steering bearings
• Check bearing assemblies for
looseness.
• Moderately repack with lithium
soap-based grease every
16000 mi (25000 km) or 24
months.
√√√√Repack. √
12 * Steering damper
• Check operation and for oil
leakage.
√√√√√
13 * Chassis fasteners
• Check all chassis fitting and
fasteners.
• Correct if necessary.
√√√√√
14
Brake and clutch
lever pivot shafts
• Apply lithium-soap-based
grease (all-purpose grease)
lightly.
√√√√√
15
Shift pedal rod
pivots
• Apply lithium-soap-based
grease (all-purpose grease)
lightly.
√√√√√
16 Sidestand pivot
• Check operation.
• Apply lithium-soap-based
grease (all-purpose grease)
lightly.
√√√√√
17 * Sidestand switch
• Check operation and replace if
necessary.
√√√√√√
18 * Front fork
• Check operation and for oil
leakage.
• Replace if necessary.
√√√√√
19 *
Shock absorber
assembly
• Check operation and for oil
leakage.
• Replace if necessary.
√√√√√
20 *
Rear suspension
link pivots
• Check operation.
• Correct if necessary.
√√
21 Engine oil
• Change (warm engine before
draining).
√√√√√√
22 *
Engine oil filter
cartridge
• Replace. √√√
NO. ITEM ROUTINE
INITIAL ODOMETER READINGS
600 mi
(1000 km)
or
1 month
4000 mi
(7000 km)
or
6 months
8000 mi
(13000 km)
or
12 months
12000 mi
(19000 km)
or
18 months
16000 mi
(25000 km)
or
24 months
20000 mi
(31000 km)
or
30 months
