Yamaha YZF-R1 (2006) [46/426] Tightening torques

TIGHTENING TORQUES

2-17

EAS20350

CHASSIS TIGHTENING TORQUES

Item

Threa

d size

Q’ty Tightening torque Remarks

Upper bracket pinch bolt M8 2 26 Nm (2.6 m·kg, 19 ft·lb)

Steering stem nut M28 1 113 Nm (11.3 m·kg, 82 ft·lb)

Handlebar pinch bolt M8 2 17 Nm (1.7m·kg, 12 ft·lb)

Handlebar bolt M6 2 13 Nm (1.3 m·kg, 9.4 ft·lb)

Cap bolt M46 2 23 Nm (2.3 m·kg, 17 ft·lb)

Lower ring nut M30 2 See NOTE

Lower bracket pinch bolt M8 4 23 Nm (2.3 m·kg, 17 ft·lb)

Brake master cylinder reservoir

cap screw

M4 1 1.2 Nm (0.12 m·kg, 0.9 ft·lb)

Front brake hose union bolt M10 3 30 Nm (3.0 m·kg, 22 ft·lb)

Front brake master cylinder

holder bolt

M6 2 13 Nm (1.3 m·kg, 9.4 ft·lb)

Meter assembly and cowling stay

screw

– 3 1.3 Nm (0.13 m·kg, 0.9 ft·lb)

Headlight and cowling stay screw – 6 0.8 Nm (0.08 m·kg, 0.6 ft·lb)

Front cowling and headlight screw – 5 1.5 Nm (0.15 m·kg, 1.1 ft·lb)

Side cowling bracket and frame

bolt

M6 2 5.0 Nm (0.5 m·kg, 3.6 ft·lb)

Under cowling and engine bolt M6 3 5.0 Nm (0.5 m·kg, 3.6 ft·lb)

Rear view mirror nut M6 4 7.0 Nm (0.7 m·kg, 5.1 ft·lb)

Front cowling and intake air duct

panel screw

M5 2 1.3 Nm (0.13 m·kg, 0.9 ft·lb)

Grip end bolt M6 2 4.0 Nm (0.4 m·kg, 2.9 ft·lb)

Horn bracket bolt M6 2 11 Nm (1.1 m·kg, 8.0 ft·lb)

Coolant reservoir bolt M6 2 5.0 Nm (0.5 m·kg, 3.6 ft·lb)

Left front engine mounting bolt M10 1 45 Nm (4.5 m·kg, 33 ft·lb)

Right front engine mounting bolt M10 1 45 Nm (4.5 m·kg, 33 ft·lb)

Engine mount self locking nut

(upper)

M10 1 51 Nm (5.1 m·kg, 37 ft·lb)

See

NOTE

Engine mount self locking nut

(lower)

M10 1 51 Nm (5.1 m·kg, 37 ft·lb)

See

NOTE

Engine mounting adjust bolt

(upper)

M16 1 7.0 Nm (0.7 m·kg, 5.1 ft·lb)

See

NOTE

Engine mounting adjust bolt

(lower)

M16 1 7.0 Nm (0.7 m·kg, 5.1 ft·lb)

See

NOTE

Clutch cable locknut (engine side) M8 1 7.0 Nm (0.7 m·kg, 5.1 ft·lb)

Main frame and rear frame bolt M10 4 41 Nm (4.1 m·kg, 30 ft·lb)

See

NOTE

Pivot shaft M30 1 7.0 Nm (0.7 m·kg, 5.1 ft·lb)

Pivot shaft ring nut M30 1 65 Nm (6.5 m·kg, 47 ft·lb)

Pivot shaft nut M20 1 105 Nm (10.5 m·kg, 76 ft·lb)
