FUEL INJECTION SYSTEM
8-58
Fault code No. 42 Symptom
ANo normal signals are received from the speed sensor.
BOpen circuit is detected in the neutral switch.
Diagnostic code No.
A 07 Speed sensor
B21Neutral switch
Orde
r
Item/components and probable
cause
Check or maintenance job
Reinstatement
method
A-1 Installed state of speed sensor. Check for looseness or pinching. Starting the
engine, and
activating the
speed sensor
by operating the
vehicle.
A-2 Connections
• Speed sensor coupler
• Main wire harness ECU coupler
• Check the couplers for any pins
that may be pulled out.
• Check the locking condition of
the couplers.
• If there is a malfunction, repair it
and connect the coupler
securely.
A-3 Open or short circuit in lead. • Repair or replace if there is an
open or short circuit.
• Between speed sensor coupler
and ECU coupler.
(Blue–Blue)
(White/Yellow–White/Yellow)
(Black/Blue–Black/Blue)
A-4 Defective speed sensor. • Execute the diagnostic mode.
(Code No. 07)
• Replace if defective.
Refer to "CHECKING THE
SPEED SENSOR" on page 8-
87.
B-1 Installed state of neutral switch. Check for looseness or pinching.
B-2 Connections
• Neutral switch coupler
• Main wire harness ECU coupler
• Check the couplers for any pins
that may be pulled out.
• Check the locking condition of
the couplers.
• If there is a malfunction, repair it
and connect the coupler
securely.
B-3 Open circuit in neutral switch lead. • Repair or replace if there is an
open circuit.
• Between neutral switch coupler
and relay unit coupler.
(Sky blue–Sky blue)
• Between relay unit coupler and
ECU coupler.
(Blue/Yellow–Blue/Yellow)
B-4 Defective neutral switch. • Execute the diagnostic mode.
(Code No.21)
• Replace if defective.
Refer to "CHECKING THE
SWITCHES" on page 8-73.
B-5 Faulty shift drum (neutral detection
area).
• Replace if defective.
Refer to "TRANSMISSION" on
page 5-84.
