FUEL PUMP SYSTEM
8-67
EAS27570
TROUBLESHOOTING
If the fuel pump fails to operate.
NOTE:
• Before troubleshooting, remove the following part(s):
1Rider seat
2 Passenger seat
3 Fuel tank
4 Side cowlings
NG→
OK↓
NG→
OK↓
NG→
OK↓
NG→
OK↓
NG→
OK↓
NG→
OK↓
1 Check the fuses.
(Main, ignition and fuel injection
system)
Refer to "CHECKING THE FUSES"
on page 8-77.
Replace the fuse(s).
2 Check the battery.
Refer to "CHECKING AND
CHARGING THE BATTERY" on
page 8-77.
• Clean the battery terminals.
• Recharge or replace the battery.
3 Check the main switch.
Refer to "CHECKING THE
SWITCHES" on page 8-73.
Replace the main switch.
4 Check the engine stop switch.
Refer to "CHECKING THE
SWITCHES" on page 8-73.
Replace the right handlebar switch.
5 Check the starting circuit cut-off
relay.
Refer to "CHECKING THE
RELAYS" on page 8-80.
Replace the starting circuit cut-off
relay.
6 Check the fuel pump.
Refer to "CHECKING THE FUEL
PRESSURE" on page 7-6.
Replace the fuel pump.
