FUEL INJECTION SYSTEM
8-41
09 Fuel system voltage
(battery voltage)
Approximately 12.0 Set the engine stop switch
to “ ”, and then compare
with the actually measured
battery voltage. (If the bat-
tery voltage is lower,
recharge the battery.)
13 Throttle position sensor (for
throttle valves) signal 2
• Fully closed position 9–23 Check with throttle valve
fully closed.
• Fully opened position 94–108 Check with throttle valve
fully opened.
14 Throttle position sensor (for
throttle cable pulley) signal
1
• Fully closed position 12–22 Check with throttle grip fully
closed.
• Fully opened position 97–107 Check with throttle grip fully
opened.
15 Throttle position sensor (for
throttle cable pulley) signal
2
• Fully closed position 10–24 Check with throttle grip fully
closed.
• Fully opened position 95–109 Check with throttle grip fully
opened.
20 Sidestand switch Set ON/OFF the sidestand
switch (with the transmis-
sion in gear).
• Stand retracted ON
• Stand extended OFF
21 Neutral switch Shift the transmission.
• Neutral ON
• In gear OFF
60 EEPROM fault cylinder No.
• No history
• History exists
00
01-04 (fault cylinder No.)
• (If more than one cylinder is
defective, the display
changes every two seconds
to show all the detected cyl-
inder numbers. When all
cylinder numbers are
shown, the display repeats.)
—
Diag-
nostic
code
No.
Item Meter display Checking method
