GENERAL CHASSIS
4-7
EAS21840
REMOVING THE COVER
1. Remove:
• Tail cover
• Rear fender
NOTE:
To remove the quick fastener, push its center
with a screwdriver, then pull the fastener out.
EAS21850
INSTALLING THE COVER
1. Install:
• Rear fender
• Tail cover
NOTE:
To install the quick fastener, push its pin so that
it protrudes from the fastener head, then insert
the fastener into the cover and push the pin “a”
in with screwdriver. Make sure that the pin is
flush with the fastener’s head.
