FUEL PUMP SYSTEM
8-68
NG→
OK↓
7 Check the entire fuel pump sys-
tem’s wiring.
Refer to "FUEL PUMP SYSTEM"
on page 8-65.
Properly connect or repair the fuel
pump system’s wiring.
Replace the ECU.
