OIL PUMP
5-58
8 Oil strainer 1
9 Oil pipe 1
10 Oil delivery pipe 1
11 Relief valve assembly 1
12 Oil/water pump assembly drive chain guide 1
13 Collar 1
14 Oil/water pump assembly drive sprocket 1
15 Washer 1
16 Oil/water pump assembly drive chain 1
17 Dowel pin 1
18 Oil/water pump assembly 1
For installation, reverse the removal proce-
dure.
