Yamaha YZF-R1 (2006) [417/426] Troubleshooting
![Yamaha YZF-R1 (2006) [417/426] Troubleshooting](/views2/1121350/page417/bg1a1.png)
9
TROUBLESHOOTING
TROUBLESHOOTING ..................................................................................9-1
GENERAL INFORMATION.....................................................................9-1
STARTING FAILURES............................................................................9-1
INCORRECT ENGINE IDLING SPEED .................................................9-1
POOR MEDIUM-AND-HIGH-SPEED PERFORMANCE ........................9-2
FAULTY GEAR SHIFTING ......................................................................9-2
SHIFT PEDAL DOES NOT MOVE..........................................................9-2
JUMPS OUT OF GEAR..........................................................................9-2
FAULTY CLUTCH ...................................................................................9-2
OVERHEATING ......................................................................................9-2
OVER COOLING ....................................................................................9-3
POOR BRAKING PERFORMANCE .......................................................9-3
FAULTY FRONT FORK LEGS ................................................................9-3
UNSTABLE HANDLING..........................................................................9-3
FAULTY LIGHTING OR SIGNALING SYSTEM ......................................9-4
