FUEL INJECTION SYSTEM
8-47
Fault code No. 14 Symptom
Intake air pressure sensor: hose system malfunction
(clogged or detached hose).
Diagnostic code No. 03 Intake air pressure sensor
Orde
r
Item/components and probable
cause
Check or maintenance job
Reinstatement
method
1 Intake air pressure sensor hose • Check the intake air pressure
sensor hose condition.
• Repair or replace the sensor
hose.
Cranking the
engine.
2 Defective intake air pressure sensor. • Execute the diagnostic mode.
(Code No. 03)
• Replace if defective.
Refer to "CHECKING THE
INTAKE AIR PRESSURE SEN-
SOR" on page 8-91.
Fault code No. 15 Symptom
Throttle position sensor (for throttle valves): open or
short circuit detected.
Diagnostic code No.
01
13
Throttle position sensor (for throttle valves) signal 1
Throttle position sensor (for throttle valves) signal 2
Orde
r
Item/components and probable
cause
Check or maintenance job
Reinstatement
method
1 Installed condition of throttle position
sensor (for throttle valves).
• Check for looseness or pinch-
ing.
• Check that the sensor is
installed in the specified posi-
tion.
Turning the
main switch to
“ON”.
2 Connections
• Throttle position sensor (for throttle
valves) coupler
• Main wire harness ECU coupler
• Check the coupler for any pins
that may be pulled out.
• Check the locking condition of
the coupler.
• If there is a malfunction, repair it
and connect the coupler
securely.
3 Open or short circuit in wire harness. • Repair or replace if there is an
open or short circuit.
• Between throttle position sensor
coupler (for throttle valves) cou-
pler and ECU coupler.
(Black/Blue–Black/Blue)
(White–White)
(Black–Black)
(Blue–Blue)
4 Defective throttle position sensor (for
throttle valves).
• Execute the diagnostic mode.
(Code Nos. 01, 13)
• Replace if defective.
Refer to "CHECKING THE
THROTTLE POSITION SEN-
SOR (FOR THROTTLE
VALVES)" on page 8-89.
