CHAIN DRIVE
4-70
EAS23400
CHAIN DRIVE
Removing the drive chain
Order Job/Parts to remove Q’ty Remarks
Swingarm Refer to "SWINGARM" on page 4-65.
1 Drive chain guard 1
2Drive chain 1
For installation, reverse the removal proce-
dure.
