CHASSIS SPECIFICATIONS
2-8
EAS20300
CHASSIS SPECIFICATIONS
Chassis
Frame type Diamond
Caster angle 24.00 °
Trail 102.0 mm (4.02 in)
Front wheel
Wheel type Cast wheel
Rim size 17M/C × MT3.50
Rim material Aluminum
Wheel travel 120.0 mm (4.72 in)
Radial wheel runout limit 1.0 mm (0.04 in)
Lateral wheel runout limit 0.5 mm (0.02 in)
Rear wheel
Wheel type Cast wheel
Rim size 17M/C × MT6.00
Rim material Aluminum
Wheel travel 130.0 mm (5.12 in)
Radial wheel runout limit 1.0 mm (0.04 in)
Lateral wheel runout limit 0.5 mm (0.02 in)
Front tire
Type Tubeless
Size 120/70 ZR17M/C (58W)
Manufacturer/model PIRELLI/DIABLO CORSA E
Manufacturer/model MICHELIN/Pilot POWER
Wear limit (front) 0.8 mm (0.03 in)
Rear tire
Type Tubeless
Size 190/50 ZR17M/C (73W)
Manufacturer/model PIRELLI/DIABLO CORSA L
Manufacturer/model MICHELIN/ Pilot POWER
Wear limit (rear) 0.8 mm (0.03 in)
Tire air pressure (measured on cold tires)
Loading condition 0–90 kg (0–198 lb)
Front 250 kPa (36 psi) (2.50 kgf/cm²) (2.50 bar)
Rear 290 kPa (42 psi) (2.90 kgf/cm²) (2.90 bar)
Loading condition 90–195 kg (198–430 lb)
Front 250 kPa (36 psi) (2.50 kgf/cm²) (2.50 bar)
Rear 290 kPa (42 psi) (2.90 kgf/cm²) (2.90 bar)
High-speed riding
Front 250 kPa (36 psi) (2.50 kgf/cm²) (2.50 bar)
Rear 290 kPa (42 psi) (2.90 kgf/cm²) (2.90 bar)
Front brake
Type Dual disc brake
Operation Right hand operation
Front brake lever free play 2.3–11.5 mm (0.09–0.45 in)
Front disc brake
Disc outside diameter × thickness 310.0 × 5.0 mm (12.20 × 0.20 in)
Brake disc thickness limit 4.5 mm (0.18 in)
Brake disc deflection limit 0.10 mm (0.0039 in)
Brake pad lining thickness (inner) 4.5 mm (0.18 in)
Limit 0.8 mm (0.03 in)
Brake pad lining thickness (outer) 4.5 mm (0.18 in)
Limit 0.8 mm (0.03 in)
