CHARGING SYSTEM
8-13
EAS27230
TROUBLESHOOTING
The battery is not being charged.
NOTE:
• Before troubleshooting, remove the following part(s):
1Rider seat
2 Fuel tank
3 Air filter case
NG→
OK↓
NG→
OK↓
NG→
OK↓
NG→
OK↓
NG→
OK↓
1 Check the fuse.
(Main)
Refer to "CHECKING THE FUSES"
on page 8-77.
Replace the fuse.
2 Check the battery.
Refer to "CHECKING AND
CHARGING THE BATTERY" on
page 8-77.
• Clean the battery terminals.
• Recharge or replace the battery.
3 Check the stator coil
Refer to "CHECKING THE STATOR
COIL" on page 8-85.
• Replace the stator coil assembly.
4 Check the rectifier/regulator.
Refer to "CHECKING THE RECTI-
FIER/REGULATOR" on page 8-85.
Replace the rectifier/regulator.
5 Check the entire charging system’s
wiring.
Refer to "CHARGING SYSTEM" on
page 8-11.
Properly connect or repair the charg-
ing system’s wiring.
This circuit is OK.
