ELECTRICAL SPECIFICATIONS
2-10
EAS20310
ELECTRICAL SPECIFICATIONS
Voltage
System voltage 12 V
Ignition system
Ignition system Transistorized coil ignition (digital)
Ignition timing (B.T.D.C.) 5.0 °/1050 r/min
Engine control unit
Model/manufacturer TBDF42/DENSO
Ignition coil
Model/manufacturer F6T568/MITSUBISHI
Minimum ignition spark gap 6.0 mm (0.24 in)
Primary coil resistance 0.85–1.15 Ω at 20 °C (68 °F)
Secondary coil resistance 5.02–6.79 kΩ at 20 °C (68 °F)
AC magneto
Model/manufacturer F4T850/MITSUBISHI
Standard output 14.0 V40.0 A5000 r/min
Stator coil resistance 0.14–0.18 Ω at 20 °C (68 °F)
Rectifier/regulator
Regulator type Semi conductor-short circuit
Model/manufacturer FH012AA/SHINDENGEN
Regulated voltage (DC) 14.2–14.8 V
Rectifier capacity 50.0 A
Withstand voltage 40.0 V
Battery
Model YTZ10S
Voltage, capacity 12 V, 8.6 Ah
Specific gravity 1.310
Manufacturer GYM
Ten hour rate amperage 0.90 A
Headlight
Bulb type Halogen bulb
Bulb voltage, wattage × quantity
Headlight 12 V, 55.0 W × 4
Auxiliary light 12 V, 5.0 W × 2
Tail/brake light LED
Front turn signal/position light 12 V, 21.0 W/5.0 W × 2
Rear turn signal light 12 V, 21.0 W × 2
License plate light 12 V, 5.0 W × 1
Meter lighting LED
Indicator light
Neutral indicator light LED
Turn signal indicator light LED
Oil level warning light LED
High beam indicator light LED
Fuel level warning light LED
Coolant temperature warning light LED
Engine trouble warning light LED
Shift timing indicator light LED
Electric starting system
System type Constant mesh
