Yamaha YZF-R1 (2006) [350/426] Cooling system
![Yamaha YZF-R1 (2006) [350/426] Cooling system](/views2/1121350/page350/bg15e.png)
COOLING SYSTEM
8-27
EAS27320
TROUBLESHOOTING
NOTE:
• Before troubleshooting, remove the following part(s):
1Rider seat
2 Passenger seat
3 Fuel tank
4Side cowling
NG→
OK↓
NG→
OK↓
NG→
OK↓
NG→
OK↓
NG→
OK↓
NG→
OK↓
NG→
OK↓
1 Check the fuses.
(Main, ignition and radiator fan
motor)
Refer to "CHECKING THE FUSES"
on page 8-77.
Replace the fuse(s).
2 Check the battery.
Refer to "CHECKING AND
CHARGING THE BATTERY" on
page 8-77.
• Clean the battery terminals.
• Recharge or replace the battery.
3 Check the main switch.
Refer to "CHECKING THE
SWITCHES" on page 8-73.
Replace the main switch.
4 Check the radiator fan motor.
Refer to "CHECKING THE RADIA-
TOR FAN MOTORS" on page 8-88.
The radiator fan motor is faulty and
must be replaced.
5 Check the radiator fan motor relay.
Refer to "CHECKING THE
RELAYS" on page 8-80.
Replace the radiator fan motor relay.
6 Check the coolant temperature.
Refer to "CHECKING THE COOL-
ANT TEMPERATURE SENSOR"
on page 8-88.
Replace the coolant temperature sen-
sor.
7 Check the entire cooling system’s
wiring.
Refer to "COOLING SYSTEM" on
page 8-25.
Properly connect or repair the cooling
system’s wiring.
This circuit is OK.
