CHAIN DRIVE
4-73
CAUTION:
ECA14300
Never install a new drive chain onto worn
drive chain sprockets; this will dramatically
shorten the drive chain’s life.
3. Adjust:
• Drive chain slack
Refer to "ADJUSTING THE DRIVE CHAIN
SLACK" on page 3-27
CAUTION:
ECA13550
A drive chain that is too tight will overload
the engine and other vital parts, and one
that is too loose can skip and damage the
swingarm or cause an accident. Therefore,
keep the drive chain slack within the speci-
fied limits.
Drive chain slack
30.0–40.0 mm (1.18–1.57 in)
