SIGNALING SYSTEM
8-22
NG→
OK↓
The tail/brake light fails to come on.
NG→
OK↓
NG→
OK↓
NG→
OK↓
NG→
OK↓
The turn signal light, turn signal indicator light or both fail to blink.
NG→
OK↓
NG→
OK↓
3 Check the entire signaling system’s
wiring.
Refer to "SIGNALING SYSTEM" on
page 8-19.
Properly connect or repair the signal-
ing system’s wiring.
This circuit is OK.
1 Check the tail/brake light bulb and
socket.
Refer to "CHECKING THE BULBS
AND BULB SOCKETS" on page 8-
76.
Replace the tail/brake light bulb,
socket or both.
2 Check the front brake light switch.
Refer to "CHECKING THE
SWITCHES" on page 8-73.
Replace the front brake light switch.
3 Check the rear brake light switch.
Refer to "CHECKING THE
SWITCHES" on page 8-73.
Replace the rear brake light switch.
4 Check the entire signaling system’s
wiring.
Refer to "SIGNALING SYSTEM" on
page 8-19.
Properly connect or repair the signal-
ing system’s wiring.
This circuit is OK.
1 Check the turn signal light bulb and
socket.
Refer to "CHECKING THE BULBS
AND BULB SOCKETS" on page 8-
76.
Replace the turn signal indicator light
bulb, socket or both.
2 Check the turn signal switch.
Refer to "CHECKING THE
SWITCHES" on page 8-73.
Replace the left handlebar switch.
