FUEL INJECTION SYSTEM
8-62
Fault code No. 60 Symptom
Throttle servo motor: open or short circuit detected.
Defective throttle servo motor.
Malfunction in ECU (servo motor driving system).
Diagnostic code No.
01
13
Throttle position sensor (for throttle valves) signal 1
Throttle position sensor (for throttle valves) signal 2
Orde
r
Item/components and probable
cause
Check or maintenance job
Reinstatement
method
1 Installed state of accelerator position
sensor (for throttle valves).
• Check for looseness or pinch-
ing.
• Check that the sensor is
installed in the specified posi-
tion.
Turning the
main switch to
“ON”.
2 Connections
• Throttle servo motor coupler
• Main wire harness ECU coupler
• Check the couplers for any pins
that may be pulled out.
• Check the locking condition of
the couplers.
• If there is a malfunction, repair it
and connect the coupler
securely.
3 Open or short circuit in wire harness. • Repair or replace if there is an
open or short circuit.
• Between throttle servo motor
coupler and ECU coupler.
(Yellow/Red–Yellow/Red)
(Light green/Red–Light green/
Red)
4 Defective throttle servo motor. • Execute the diagnostic mode.
(Code Nos. 01, 13)
• Replace the throttle body
assembly if defective.
5 Malfunction in ECU. Replace the ECU.
Fault code No. Er-1 Symptom No signals are received from the ECU.
Diagnostic code No. — —
Orde
r
Item/components and probable
cause
Check or maintenance job
Reinstatement
method
1 Connections
• Main wire harness ECU coupler
• Main wire harness meter assembly
coupler
• Check the couplers for any pins
that may be pulled out.
• Check the locking condition of
the coupler.
• If there is a malfunction, repair it
and connect the coupler
securely.
Turning the
main switch to
“ON”.
2 Open or short circuit in wire harness. • Repair or replace if there is an
open or short circuit.
• Between meter assembly cou-
pler and ECU coupler.
(Yellow/Blue–Yellow/Blue)
3 Malfunction in meter assembly. Replace the meter assembly.
4 Malfunction in ECU. Replace the ECU.
