FUEL INJECTION SYSTEM
8-33
20
Intake air pressure
sensor
Atmospheric pressure
sensor
Intake air pressure sensor-open or
short circuit detected.
Defective values are detected due
to the internal malfunction of the
intake air pressure sensor or the
Atmospheric pressure sensor.
Able Able
21
Coolant temperature
sensor
Coolant temperature sensor-open
or short circuit detected.
Able Able
22
Intake air temperature
sensor
Intake air temperature sensor-
open or short circuit detected.
Able Able
23
Atmospheric pressure
sensor
Atmospheric pressure sensor-
open or short circuit detected.
Able Able
24
O
2
sensor
No normal signal is received from
the O
2
sensor.
Able Able
30 Lean angle sensor
Latch up detected.
No normal signal is received from
the lean angle sensor.
Unable Unable
33
Ignition coil (#1)
(faulty ignition)
Malfunction detected in the pri-
mary wire of the ignition coil (#1).
Able
(depending
on the num-
ber of faulty
cylinders)
Able
(depending
on the num-
ber of faulty
cylinders)
34
Ignition coil (#2)
(faulty ignition)
Malfunction detected in the pri-
mary wire of the ignition coil (#2).
Able
(depending
on the num-
ber of faulty
cylinders)
Able
(depending
on the num-
ber of faulty
cylinders)
35
Ignition coil (#3)
(faulty ignition)
Malfunction detected in the pri-
mary wire of the ignition coil (#3).
Able
(depending
on the num-
ber of faulty
cylinders)
Able
(depending
on the num-
ber of faulty
cylinders)
36
Ignition coil (#4)
(faulty ignition)
Malfunction detected in the pri-
mary wire of the ignition coil (#4).
Able
(depending
on the num-
ber of faulty
cylinders)
Able
(depending
on the num-
ber of faulty
cylinders)
39
Injector
(open circuit)
Injector:
open circuit detected.
Able
(depending
on the num-
ber of faulty
cylinders)
Able
(depending
on the num-
ber of faulty
cylinders)
41
Lean angle sensor
(open or short circuit)
Lean angle sensor-open or short
circuit detected.
Unable Unable
42
Speed sensor
Neutral switch
No normal signals are received
from the speed sensor.
Open or short circuit is detected in
the neutral switch.
Able Able
Fault
code No.
Item Symptom
Able /
unable to
start
Able /
unable to
drive
