FUEL INJECTION SYSTEM
8-54
Fault code No. 35 Symptom
Open circuit detected in the primary lead of the cylinder-
#3 ignition coil.
Diagnostic code No. 32 Cylinder-#3 ignition coil
Orde
r
Item/components and probable
cause
Check or maintenance job
Reinstatement
method
1 Connections
• Cylinder-#3 ignition coil coupler
• Main wire harness ECU coupler
• Sub-wire harness 1 coupler
• Check the couplers for any pins
that may have pulled out.
• Check the locking condition of
the couplers.
• If there is a malfunction, repair it
and connect the coupler
securely.
Cranking the
engine.
(Connect the
cylinder-#3 igni-
tion coil cou-
pler.)
2 Open or short circuit in wire harness
and/or sub-wire harness 1.
• Repair or replace if there is an
open or short circuit.
• Between cylinder-#3 ignition
coil coupler and ECU coupler.
(Red/Black–Red/Black)
(Orange/Green–Orange/Green)
3 Defective cylinder-#3 ignition coil. • Execute the diagnostic mode.
(Code No.32)
• Test the primary and secondary
coils for continuity.
• Replace if defective.
Refer to "CHECKING THE
IGNITION COILS" on page 8-
83.
