ENGINE REMOVAL
5-4
Disassembling the exhaust valve pipe
Order Job/Parts to remove Q’ty Remarks
1 Washer 1
2 Pulley 1
3 Collar 1
4Plate 1
5Spring 1
6 EXUP pulley bracket 1
7 Housing 1
8Gasket 1
9 Collar 1
10 Shaft arm 1
11 Exhaust valve pipe 1
For assembly, reverse the disassembly pro-
cedure.
