PERIODIC MAINTENANCE
3-3
* Since these items require special tools, data and technical skills, have a Yamaha dealer perform
the service.
NOTE:
From 24000 mi (37000 km) or 36 months, repeat the maintenance intervals starting from 8000 mi
(13000 km) or 12 months.
NOTE:
• Air filter
• This model’s air filter is equipped with a disposable oil-coated paper element, which must not be
cleaned with compressed air to avoid damaging it.
• The air filter element needs to be replaced more frequently when riding in unusually wet or dusty
areas.
• Hydraulic brake service
• After disassembling the brake master cylinders and calipers, always change the fluid. Regularly
check the brake fluid levels and fill the reservoirs as required.
• Every two years replace the internal components of the brake master cylinders and calipers, and
change the brake fluid.
• Replace the brake hoses every four years and if cracked or damaged.
23 * Cooling system
• Check hoses for cracks or
damage.
• Replace if necessary.
√√√√√
• Change with ethylene glycol
antifreeze coolant every 24
months.
Change.
24 * EXUP system
• Check operation, cable free
play and pulley position.
√√√√√
25 *
Front and rear
brake switches
• Check operation. √ Every 12000 mi (19000 km)
26 * Control cables
• Apply Yamaha chain and cable
lube or engine oil SAE 10W-30
thoroughly.
√√√√√√
27 *
Throttle grip hous-
ing and cable
• Check operation and free play.
• Adjust the throttle cable free
play if necessary.
• Lubricate the throttle grip
housing and cable.
√√√√√
28 *
Lights, signals
and switches
• Check operation.
• Adjust headlight beam.
√√√√√√
NO. ITEM ROUTINE
INITIAL ODOMETER READINGS
600 mi
(1000 km)
or
1 month
4000 mi
(7000 km)
or
6 months
8000 mi
(13000 km)
or
12 months
12000 mi
(19000 km)
or
18 months
16000 mi
(25000 km)
or
24 months
20000 mi
(31000 km)
or
30 months
