Yamaha YZF-R1 (2006) [40/426] Electrical specifications
![Yamaha YZF-R1 (2006) [40/426] Electrical specifications](/views2/1121350/page40/bg28.png)
ELECTRICAL SPECIFICATIONS
2-11
Starter motor
Model/manufacturer 5VY/YAMAHA
Power output 0.90 kW
Armature coil resistance 0.0090–0.0110 Ω
Brush overall length 10.8 mm (0.43 in)
Limit 7.19 mm (0.28 in)
Brush spring force 5.28–7.92 N (19.01–28.51 oz) (538–808 gf)
Commutator diameter 24.5 mm (0.96 in)
Limit 23.5 mm (0.93 in)
Mica undercut (depth) 1.50 mm (0.06 in)
Starter relay
Model/manufacturer 2768093-A/JIDECO
Amperage 180.0 A
Coil resistance 4.18–4.62 Ω
Horn
Horn type Plane
Quantity 1 pcs
Model/manufacturer YF-12/NIKKO
Maximum amperage 3.0 A
Coil resistance 1.15–1.25 Ω
Performance 105–113 dB/2m
Turn signal relay
Relay type Full transistor
Model/manufacturer FE246BS/DENSO
Built-in, self-canceling device No
Turn signal blinking frequency 75.0–95.0 cycles/min
Wattage 21 W × 2.0 +3.4 W
Oil level gauge
Model/manufacturer 5VY/SOMIC ISHIKAWA
Servo motor
Model/manufacturer 5VY/YAMAHA
Fuses
Main fuse 50.0 A
Headlight fuse 25.0 A
Signaling system fuse 7.5 A
Ignition fuse 15.0 A
Radiator fan fuse 15.0 A × 2
Backup fuse 7.5 A
Electric throttle valve fuse 7.5 A
Reserve fuse 25.0 A
Reserve fuse 15.0 A
Reserve fuse 7.5 A
