Yamaha YZF-R1 (2006) [47/426] Tightening torques
![Yamaha YZF-R1 (2006) [47/426] Tightening torques](/views2/1121350/page47/bg2f.png)
TIGHTENING TORQUES
2-18
NOTE:
• Lower ring nut
1. First, tighten the lower ring nut approximately 52 Nm (5.2 m·kg, 38 ft·lb) by using the torque
wrench, then loosen the ring nut completely.
2. Retighten the lower ring nut 18 Nm (1.8 m·kg, 13 ft·lb).
Connecting arm nut (connecting
arm and frame)
M10 1 44 Nm (4.4 m·kg, 32 ft·lb)
Relay arm nut (relay arm and
connecting arm)
M10 1 44 Nm (4.4 m·kg, 32 ft·lb)
Relay arm nut (relay arm and
swingarm)
M10 1 44 Nm (4.4 m·kg, 32 ft·lb)
Rear shock absorber assembly
lower nut
M10 1 44 Nm (4.4 m·kg, 32 ft·lb)
Rear shock absorber upper
bracket nut
M10 1 44 Nm (4.4 m·kg, 32 ft·lb)
Rear shock absorber assembly
upper nut
M10 1 92 Nm (9.2 m·kg, 67 ft·lb)
Drive chain guard bolt M6 2 7.0 Nm (0.7 m·kg, 5.1 ft·lb)
Drive chain guide bolt M6 1 13 Nm (1.3 m·kg, 9.4 ft·lb)
Drive chain adjusting locknut M8 2 16 Nm (1.6 m·kg, 12 ft·lb)
Fuel pump bolt M5 6 4.0 Nm (0.4 m·kg, 2.9 ft·lb)
Fuel tank bolt (front) M6 1 7.0 Nm (0.7 m·kg, 5.1 ft·lb)
Fuel tank bracket bolt M6 2 7.0 Nm (0.7 m·kg, 5.1 ft·lb)
Fuel tank bolt (rear) M6 4 7.0 Nm (0.7 m·kg, 5.1 ft·lb)
Fuel tank side cover screw M5 2 4.0 Nm (0.4 m·kg, 2.9 ft·lb)
Rider seat bolt M6 2 7.0 Nm (0.7 m·kg, 5.1 ft·lb)
Seat lock assembly bolt M6 2 10 Nm (1.0 m·kg, 7.2 ft·lb)
Upper tail cover bolt M5 1 4.0 Nm (0.4 m·kg, 2.9 ft·lb)
Battery box bolt M6 2 7.0 Nm (0.7 m·kg, 5.1 ft·lb)
Lean angle sensor bolt M4 2 2.0 Nm (0.2 m·kg, 1.4 ft·lb)
Footrest bracket bolt M8 4 28 Nm (2.8 m·kg, 20 ft·lb)
Rear brake master cylinder bolt M8 2 23 Nm (2.3 m·kg, 17 ft·lb)
Rear brake hose union bolt M10 2 30 Nm (3.0 m·kg, 22 ft·lb)
Sidestand and bracket nut M10 1 61 Nm (6.1 m·kg, 44 ft·lb)
Sidestand bracket and frame bolt M10 2 63 Nm (6.3 m·kg, 46 ft·lb)
Front wheel axle bolt M14 1 91 Nm (9.1 m·kg, 66 ft·lb)
Rear wheel axle nut M24 1 150 Nm (15.0 m·kg, 108 ft·lb)
Front brake caliper bolt M10 4 35 Nm (3.5 m·kg, 25 ft·lb)
Front brake disc bolt M6 10 18 Nm (1.8 m·kg, 13 ft·lb)
Rear brake disc bolt M8 5 30 Nm (3.0 m·kg, 22 ft·lb)
Rear wheel sprocket nut M10 6 100 Nm (10.0 m·kg, 72 ft·lb)
Brake caliper bleed screw M8 3 6.0 Nm (0.6 m·kg, 4.3 ft·lb)
Front wheel axle pinch bolt M8 4 21 Nm (2.1 m·kg, 15 ft·lb)
See
NOTE
Item
Threa
d size
Q’ty Tightening torque Remarks
LT
LT
LT
LT
