FUEL INJECTION SYSTEM
8-50
Fault code No. 21 Symptom
Coolant temperature sensor: open or short circuit
detected.
Diagnostic code No. 06 Coolant temperature sensor
Orde
r
Item/components and probable
cause
Check or maintenance job
Reinstatement
method
1 Connections
• Coolant temperature sensor coupler
• Main wire harness ECU coupler
• Check the coupler for any pins
that may have pulled out.
• Check the locking condition of
the couplers.
• If there is a malfunction, repair it
and connect the coupler
securely.
Reinstated
automatically if
a normal signal
is received.
2 Open or short circuit in wire harness. • Repair or replace if there is an
open or short circuit.
• Between coolant temperature
sensor coupler and ECU cou-
pler.
(Green/White–Green/White)
(Black/Blue–Black/Blue)
3 Defective coolant temperature sensor. • Execute the diagnostic mode.
(Code No.06)
• Replace if defective.
Refer to "CHECKING THE
COOLANT TEMPERATURE
SENSOR" on page 8-88.
Fault code No. 22 Symptom Air temperature sensor: open or short circuit detected.
Diagnostic code No. 05 Air temperature sensor
Orde
r
Item/components and probable
cause
Check or maintenance job
Reinstatement
method
1 Connections
• Air temperature sensor coupler
• Main wire harness ECU coupler
• Check the coupler for any pins
that may have pulled out.
• Check the locking condition of
the coupler.
• If there is a malfunction, repair it
and connect the coupler
securely.
Reinstated
automatically if
a normal signal
is received.
2 Open or short circuit in wire harness. • Repair or replace if there is an
open or short circuit.
• Between air temperature sensor
coupler and ECU coupler.
(Brown/White–Brown/White)
(Black/Blue–Black/Blue)
3 Defective air temperature sensor. • Execute the diagnostic mode.
(Code No.05)
• Replace if defective.
Refer to "CHECKING THE
INTAKE AIR TEMPERATURE
SENSOR" on page 8-91.
