FUEL INJECTION SYSTEM
8-59
Fault code No. 43 Symptom
Power supply to the injectors and fuel pump is not nor-
mal.
Diagnostic code No. 09 Fuel system voltage (battery voltage)
Orde
r
Item/components and probable
cause
Check or maintenance job
Reinstatement
method
1 Connections
• Relay unit coupler (fuel pump relay)
• Main wire harness ECU coupler
• Check the coupler for any pins
that may have pulled out.
• Check the locking condition of
the coupler.
• If there is a malfunction, repair it
and connect the coupler
securely.
Turning the
main switch to
“ON” when the
engine stop
switch is set to
“ ”.
2 Open or short circuit in the wire har-
ness.
• Repair or replace if there is an
open or short circuit.
• Between relay unit coupler and
ECU coupler.
(Blue/Yellow–Blue/Yellow)
(Red/Blue–Red/Blue)
• Between relay unit coupler and
starter relay coupler.
(Red–Red)
• Between relay unit coupler and
right handlebar switch coupler.
(Red/Black–Red/Black)
3 Malfunction or open circuit in fuel
pump relay.
• Execute the diagnostic mode.
(Code No. 09)
• Replace if defective.
• If there is no malfunction with
the fuel pump relay, replace the
ECU.
Fault code No. 44 Symptom
An error is detected while reading or writing on EEPROM
(CO adjustment value).
Diagnostic code No. 60 EEPROM fault cylinder No.
Orde
r
Item/components and probable
cause
Check or maintenance job
Reinstatement
method
1 Malfunction in ECU. • Set the faulty cylinder’s exhaust
gas volume.
1 Execute the diagnostic mode
(Code No. 60) to check the
faulty cylinder number. (If mul-
tiple cylinders are defective,
the numbers of the faulty cyl-
inders are displayed alter-
nately at 2-second intervals.)
2 Execute the CO adjustment
mode and set the exhaust gas
volume of the faulty cylinder to
“0”.
• Replace ECU if it does not
recover from the malfunction.
Turning the
main switch to
“ON”.
(Readjust the
exhaust gas vol-
ume after it is
reinstated.)
