Yamaha YZF-R1 (2006) [44/426] Tightening torques

TIGHTENING TORQUES

2-15

NOTE:

• Cylinder head nut (2 pieces)

1. First, tighten the bolts to 10 Nm (1.0 m·kg, 7.2 ft·lb) with a torque wrench following the tighten-

ing order.

2. Second, tighten the bolts to 25 Nm (2.5 m·kg, 18 ft·lb) with a torque wrench following the tight-

ening order.

3. Third, tighten the bolts to 40 Nm (4.0 m·kg, 29 ft·lb) with a torque wrench following the tighten-

ing order.

4. Final, tighten the bolts to 55 Nm (5.5 m·kg, 40 ft·lb) with a torque wrench following the tighten-

ing order.

• Cylinder head nut (8 pieces)

1. First, tighten the bolts to 10 Nm (1.0 m·kg, 7.2 ft·lb) with a torque wrench following the tighten-

ing order.

2. Second, tighten the bolts to 25 Nm (2.5 m·kg, 18 ft·lb) with a torque wrench following the tight-

ening order.

Oil return pipe bolt M6 2 10 Nm (1.0 m·kg, 7.2 ft·lb)

Oil return plug M12 2 24 Nm (2.4 m·kg, 17 ft·lb)

AC magneto lead bolt M6 1 10 Nm (1.0 m·kg, 7.2 ft·lb)

Stator coil screw M6 3 14 Nm (1.4 m·kg, 10 ft·lb)

Generator rotor cover screw M6 3 10 Nm (1.0 m·kg, 7.2 ft·lb)

Thermostat assembly stay bolt M6 2 10 Nm (1.0 m·kg, 7.2 ft·lb)

Starter clutch idler gear bolt M6 1 10 Nm (1.0 m·kg, 7.2 ft·lb)

Clutch boss nut M20 1 115 Nm (11.5 m·kg, 83 ft·lb)

Use a lock

washer

Clutch spring bolt M6 6 10 Nm (1.0 m·kg, 7.2 ft·lb)

Drive sprocket nut M22 1 85 Nm (8.5 m·kg, 61 ft·lb)

Use a lock

washer

Bearing plate bolt M6 3 12 Nm (1.2 m·kg, 8.7 ft·lb)

Shift bar stopper plate bolt M6 2 10 Nm (1.0 m·kg, 7.2 ft·lb)

Stopper screw M8 1 22 Nm (2.2 m·kg, 16 ft·lb)

Shift rod nut M6 1 6.5 Nm (0.65 m·kg, 4.7 ft·lb)

Left

thread

Shift rod nut M6 1 6.5 Nm (0.65 m·kg, 4.7 ft·lb)

Joint rod bolt M6 1 10 Nm (1.0 m·kg, 7.2 ft·lb)

Shift arm bolt M6 1 10 Nm (1.0 m·kg, 7.2 ft·lb)

Neutral switch M10 1 20 Nm (2.0 m·kg, 14 ft·lb)

Coolant temperature sensor M12 1 18 Nm (1.8 m·kg, 13 ft·lb)

Cylinder identification sensor bolt M6 1 8.0 Nm (0.8 m·kg, 5.8 ft·lb)

Atmospheric pressure sensor

screw

M5 2 7.0 Nm (0.7 m·kg, 5.0 ft·lb)

Crankshaft position sensor bolt M6 1 10 Nm (1.0 m·kg, 7.2 ft·lb)

Oil level switch bolt M6 2 10 Nm (1.0 m·kg, 7.2 ft·lb)

Item

Threa

d size

Q’ty Tightening torque Remarks
