![Yamaha YZF-R1 (2006) [267/426] Oil pump](/img/pdf.png)
Yamaha YZF-R1 (2006) [267/426] Oil pump
![Yamaha YZF-R1 (2006) [267/426] Oil pump](/views2/1121350/page267/bg10b.png)
OIL PUMP
5-64
WARNING
EWA12820
Always use new copper washers.
NOTE:
• Tighten the oil pan bolts in stages and in a
crisscross pattern.
• Lubricate the oil level switch O-ring with
engine oil.
Engine oil drain bolt
43 Nm (4.3 m·kg, 31 ft·lb)
