Section 04 ENGINE (4-TEC)
Subsection 03 (COOLING SYSTEM)
2
A32C83A
1
1. Side hose location
2. Bottom hose
Let coolant drain.
Refilling the System
With vehicle on a flat surface, engine cold, slowly
half fill coolant tank no. 28. Coolant level must
not reach bleed hose nipple to allow air to escape
from the system.
1
A32C84A
1. Bleed hose nipple
Coolant level will be stable once coolant tank is
half filled.
Do not install the pressure cap no. 30.
Start engine. Check level in coolant tank. Refill
with coolant to keep coolant tank half filled.
CAUTION: Never allow coolant tank to be emp-
ty during the filling procedure.
Let engine idling for about 10 minutes or until radi-
ators are warm which means that the thermo-
stat is open.
Keep engine idling for an additional 5 minutes
maximum or until coolant temperature reaches
100°C(212°F). Always keep coolant tank half
filled but the bleed hose free.
CAUTION: Neverallow coolant to exceed 100°C
(212°F). Put a thermometer in coolant tank to
monitor the temperature.
Stop engine. Fill up both coolant tank no. 28 and
overflow coolant tank no. 29. Install their respec-
tive caps.
Let vehicle cool down for at least 30 minutes.
Check coolant level in overflow coolant tank
no. 29. Some coolant should have been sucked
through the overflow hose up to the coolant tank.
If not repeat refilling procedure.
If some coolant have been siphoned from the
overflow coolant tank no. 29, remove pressure
cap no. 30 and fill up the coolant tank no. 28.
Reinstall pressure cap no. 30.
Fill overflow coolant tank no. 29 to maximum level
line.
Recheck coolant level after vehicle has completely
cooled down. Coolant tank no. 28 must be full and
the level in overflow coolant tank no. 29 must be
between the minimum and maximum marks.
1
A32C76A
2
1. Minimum
2. Maximum
mmr2005-023 187
