Section12TECHNICALDATA
Subsection 01 (ENGINES)
TUNDRA
ENGINE TYPE
277
FUEL SYSTEM
Carburetor type PTO/MAG 1 x VM 34-585
Main jet PTO/MAG 200
Needle jet 159 O-8
Pilot jet 40
Needle identification — clip position PTO/MAG 6DH4-3
Slide cut-away 2.5
Float adjustment mm (in) 23.9 (.94) ± 1 (.040)
Air or pilot screw adjustment ±1/16turn 1
Idle speed ±200RPM 1650
Typ e Regular unleaded gasoline
Gas
Octane number
North America: 87 (R+M)/2
Elsewhere: 91 RON
Gas/oil ratio
Injection
COOLING SYSTEM
Type Radial Fan
Deflection mm (in) N.A.
Axial fan belt adjustment
Force kg (lbf) N.A.
Coolant N.A.
Thermostat opening temperature
°C(°F)
N.A.
Radiator cap opening pressure
kPa
(PSI)
N.A.
TIGHTENING TORQUE (engine cold)
Drive pulley retaining screw
N•m
(lbf•ft)
(5)
Exhaust manifold nuts or bolts
N•m
(lbf•ft)
25 (18)
Magnetoringnut
N•m
(lbf•ft)
95 (70)
M6
N•m
(lbf•
in)
N.A.
Crankcase nuts or screws
M8
N•m
(lbf•ft)
22 (16)
Crankcase/engine support nuts or screws
N•m
(lbf•ft)
21 (15)
Cylinder head screws or nuts
N•m
(lbf•ft)
27 (20)
Crankcase/cylinder nuts or screws
N•m
(lbf•ft)
N.A.
Axial fan shaft nut
N•m
(lbf•ft)
N.A.
550 mmr2005-057
