Section 12 TECHNICAL DATA
Subsection 01 (FAN COOLED MODELS)
GSX/GTX/MX Z
EXPEDITION/SUMMIT/
GSX/GTX/MX Z
MODEL
380 F 550 F
Skistance(carbidetocarbide) mm (in) 1080 (42.5)
Toe-out mm (in) 0.00
Camber 0°
EXPEDITION — 7968 cm
2
(1235 in
2
)
GSX/MX Z 6947 cm
2
(1077 in
2
)
GTX 7633 cm
2
(1183 in
2
)
SUMMIT — 8210 cm
2
(1273 in
2
)
Ground contact area
SUMMIT (EUR) — 8545 cm
2
(1324 in
2
)
EXPEDITION — 2.56 kPa (.371 PSI)
GSX 2.82 kPa (.409 PSI) 2.95 kPa (.428 PSI)
GTX 2.70 kPa (.392 PSI) 2.83 kPa (.410 PSI)
MX Z 2.63 kPa (.381 PSI) 2.75 kPa (.399 PSI)
SUMMIT — 2.39 kPa (.347 PSI)
Ground contact pressure
SUMMIT (EUR) — 2.30 kPa (.334 PSI)
Frame material Aluminum
Bottom pan material Impact Copolymer
Hood material Surlyn
Side Panels Polypropylene
CAPACITIES
Fuel tank L (U.S. gal) 40 (10.6)
Chaincase/gearbox mL (U.S. oz) 250 (8.5)
Cooling system L(U.S.oz) N.A.
Injection oil reservoir L(U.S.oz) 3.5 (118.4)
TIGHTENING TORQUE (engine cold)
Drive pulley retaining screw (5)
Exhaust manifold nuts or bolts 22 N•m(16lbf•ft)
Magneto ring nut 105 N•m(77lbf•ft)
M6 N.A.
Crankcase nuts or screws
M8 22 N•m(16lbf•ft)
Crankcase/engine support nuts or screws 40 N•m(30lbf•ft)
Cylinder head screws 22 N•m(16lbf•ft)
Crankcase/cylinder nuts or screws N.A.
Axial fan shaft nut 48 N•m(35lbf•ft)
mmr2005-101 469
