![Ski-Doo Ski Doo MX Z 2005 [1398/1429] Cables](/views2/1012747/page1398/bg576.png)
Section11BODY/FRAME
Subsection 01 (BODY)
WIRING HARNESS
WARNING
Ensure all terminals are properly crimped on
the wires and that all connector housings are
properly fastened. Keep wires away from
any rotating, moving, heating and vibrating
parts. Use proper fastening devices as re-
quired.
CABLES
WARNING
Before installation, ensure that all cables are
in perfect condition. Properly install the cable
ends and secure them in place. Pay attention
to route them properly, away from any rotat-
ing, moving, heating, or vibrating parts.
TUBING
WARNING
Always ensure that the fuel, vent, primer, im-
pulse, injection oil and rotary valve oil lines
are properly fixed to their connectors, that
they are not perforated or kinked and that
they are properly routed away from any rotat-
ing, moving, heating or vibrating parts. Also
check for leaks. Replace if required.
NOTE: Refer to proper Parts Catalog to find suit-
able clip part numbers.
PLASTIC MAINTENANCE
AND REPAIR
MAINTENANCE
Clean the vehicle thoroughly, removing all dirt and
grease accumulation.
To clean use a soft clean cloth and either soapy
water or isopropyl alcohol.
To remove grease, oil or glue use isopropyl alco-
hol.
CAUTION: Do not apply isopropyl alcohol or
acetone directly on decals.
CAUTION: The following products must not be
used to clean or wax any of the plastic compo-
nents used on the vehicles:
– gasoline
– brake fluid
– kerosene
– diesel fuel
– lighter fluid
– varsol
– naphtha
– acetone
– strong detergents
– abrasive cleaners
– waxes containing an abrasive or a cleaning
agent in their formula.
Apply wax on glossy finish only. Protect the ve-
hicle with a cover to prevent dust accumulation
during storage.
CAUTION: If for some reason the snowmobile
has to be stored outside it is preferable to cov-
er it with an opaque tarpaulin. This will prevent
the sun rays from affecting the plastic compo-
nents and the vehicle finish.
REPAIR
The very first step before repairing plastic materi-
als is to find out exactly which type of material is
involved. Refer to following chart.
CAUTION: Consult chart and repair kit instruc-
tions carefully, some repair products are not
compatible with certain plastics.
WARNING
Polycarbonate windshields must never be re-
paired by welding or otherwise.
mmr2005-055 543
