Section12TECHNICALDATA
Subsection 01 (FAN COOLED MODELS)
GSX/GTX/MX Z
EXPEDITION/SUMMIT/
GSX/GTX/MX Z
MODEL
380 F 550 F
GSX/GTX/MX Z 381 mm (15 in)
SUMMIT — 381 mm (15 in)
Width
EXPEDITION/
SUMMIT (EUR)
— 406 mm (16 in)
GSX/MX Z 3074 mm (121 in)
GTX 3456 mm (136 in)Length
EXPEDITION/SUMMIT — 3456 mm (136 in)
GSX/MXZ 18.4 mm (.724 in) 22.3 mm (.878 in)
MX Z (EUR) 25.4 mm (1.0 in) 31.8 mm (1.25 in)
GTX 18.4 mm (.724 in) 22.3 mm (.878 in)
GTX (EUR) 22.3 mm (.878 in) 22.3 mm (.878 in)
EXPEDITION/
SUMMIT (EUR)
— 31.8 mm (1.25 in)
Track
Profile height
SUMMIT — 38.1 mm (1.50 in)
Deflection mm (in) 30 to 35 (1-3/16 to 1-3/8)
Track adjustment
Force (9) kg (lbf) 7.3 (16)
GSX/MX Z SC 3 121 in
GTX SC-136 inTrack
EXPEDITION/SUMMIT — SC-136 in
Suspension type
Ski R.A.S. A-Arm
BRAKE
Brake fluid reservoir mL (U.S. oz) 60 (2.0)
GTLMA (DOT 4) (P/N 293 600 062)
Brake fluid
Racing brake fluid SRF (DOT 4) (P/N 293 600 063)
VEHICLE INFORMATIONS
Manual start — 208 kg (458 lb)
EXPEDITION
Electric start — 220 kg (484 lb)
GSX Electric start 200 kg (440 lb) 209 kg (460 lb)
GTX Electric start 210 kg (462 lb) 220 kg (484 lb)
MX Z Manual start 186 kg (409 lb) 195 kg (429 lb)
Mass (dry)
SUMMIT Manual start — 200 kg (440 lb)
EXPEDITION — 3072 mm (121 in)
GSX/MX Z 2830 mm (111 in)
GTX 3072 mm (121 in)
Length
SUMMIT — 3045 mm (120 in)
EXPEDITION — 1150 mm (45.2 in)
GSX/GTX/MX Z 1150 mm (45.2 in)Width
SUMMIT — 1139 mm (44.8 in)
EXPEDITION — 1230 mm (48.4 in)
GSX 1160 mm (45.6 in)
GTX 1230 mm (48.4 in)
MX Z 1105 mm (43.5 in)
Height
SUMMIT — 1122 mm (44.1 in)
468 mmr2005-101
