Ski-Doo Ski Doo MX Z 2005 [1301/1429] Activation of new battery

Section08ELECTRICAL

Subsection 04 (BATTERY)

CAUTION: Do not install a partially charged

battery on a snowmobile since the casing

might crack at freezing temperature. The fol-

lowing chart shows the freezing point of the

electrolyte in relation to the temperature cor-

rected specific gravity.

TEMPERATURE

CORRECTED

SPECIFIC

GRAVITY

FREEZING POINT OF

ELECTROLYTE

1.265

-59°C

(- 75°F)

1.225

-37°C

(- 35°F)

1.200

-27°C

(- 17°F)

1.150

-15°C

(+ 5°F)

1.110

-3°C

(+ 27°F)

Voltmeter Test

Skandic WT/SWT/SUV/Expedition TUV

NOTE: To determine the battery state of charge,

these sealed batteries have to be tested with a

voltmeter. They also need to be tested when their

voltage is stabilized. Disconnect battery to have

open connectors and wait 1-2 hours prior to read-

ing the voltage. The same condition is required

after a battery has been charged.

Batteries with a voltage above 12.8 V do not need

to be charged.

Batteries with a voltage of 12.8 V and below need

to be charged. Refer to BATTERY CHARGING be-

low.

BATTERY STORAGE

Skandic LT E

Disconnect and remove battery from the vehicle.

Check electrolyte level in each cell, add distilled

water up to upper level line.

CAUTION: Do not overfill.

The battery must always be stored in fully charged

condition. If required, charge until specific gravity

of 1.265 is obtained.

CAUTION: Battery electrolyte temperature

must not exceed 50°C(122°F). The casing

should not feel hot.

Clean battery terminals and cable connections us-

ing a wire brush. Apply a light coat of silicone di-

electric grease (P/N 293 550 004) or petroleum jel-

ly on terminals.

Clean battery casing and caps using a solution of

baking soda and water. Do not allow cleaning so-

lution to enter battery, otherwise it will destroy the

electrolyte. Rinse battery with clear water and dry

well using a clean cloth.

Store battery in a cool dry place. Such conditions

reduce self-discharging and keep fluid evaporation

to a minimum.

During the storage period, recheck electrolyte lev-

el and specific gravity readings at least every 40

days. As necessary, keep the battery at its upper

level line and near full charge as possible (trickle

charge).

Skandic WT/SWT/SUV/Expedition TUV

CAUTION: A discharged battery will freeze and

it may damage its casing. A damaged casing

will allow electrolyte spillage that may damage

surrounding parts.

Disconnect and remove battery from the vehicle.

The battery must always be stored in fully charged

condition.

Clean battery terminals and cable connections us-

ing a wire brush. Apply a light coat of silicone di-

electric grease (P/N 293 550 004) or petroleum jel-

ly on terminals.

Clean battery casing using a solution of baking so-

da and water. Rinse battery with clear water and

dry well using a clean cloth.

Charge the battery every month if stored at a tem-

perature below 15°C(60°F).

Charge the battery every two weeks if stored at a

temperature above 15°C(60°F).

ACTIVATION OF NEW BATTERY

Skandic WT/SWT/SUV/Expedition TUV

Refer to the instructions provided with the battery.

Skandic LT E



WARNING

Never charge or boost battery while installed

on vehicle.

442 mmr2005-045
