Section12TECHNICALDATA
Subsection 02 (VEHICLES)
SKANDIC
WT
552
SWT
552
WT LC
593
ELECTRICAL
Battery
V(Ah)
12 (18) 12 (18) 12 (18)
Headlamp W H4 60/55 H4 60/55 H4 60/55
Taillight and stoplight W 8/27 8/27 8/27
Tachometer and speedometer bulbs W 3 3 3
Fuel and temperature gauge bulbs W N.A. N.A. N.A.
Starter solenoid A 20 20 15
Fuse
Fuel level sensor A N.A. N.A. N.A.
CAPACITIES
Fuel tank
L (U.S. gal)
40 (10.6) 40 (10.6) 40 (10.6)
Chaincase/gearbox mL (U.S. oz) 400 (13.5) 400 (13.5) 400 (13.5)
Cooling system
L(U.S.oz)
N.A. N.A.
4.5 (152)
Injection oil reservoir L (U.S. oz) 2.5 (84.5) 2.5 (84.5) 2.5 (84.5)
VEHICLE INFORMATIONS
Mass (dry) kg (lb) 258 (568) 277 (610) 275 (605)
Length
mm (in)
3020 (118.9) 3150 (124.0) 3150 (124.0)
Width mm (in) 1045 (41.1) 1100 (43.3) 1100 (43.3)
Height
mm (in)
1295 (50.98) 1330 (52.4) 1220 (48)
Ski stance (carbide to carbide) mm (in) 900 (35.4) 900 (35.4) 900 (35.4)
Toe-out
mm (in)
5 (3/16) 5 (3/16) 5(3/16)
Camber mm (in) N.A. N.A. N.A.
Ground contact area
cm
2
(in
2
) 10793 (1672.9) 13986 (2167.8) 12335 (1912)
Ground contact pressure kPa (PSI) 2.46 (.357) 2.04 (.296) 2.33 (.338)
Frame material Steel Steel Steel
Bottom pan material
Polyethylene
High Density
Polyethylene
High Density
Polyethylene
High Density
Hood material RRIM RRIM RRIM
562 mmr2005-057
