Section 02 TROUBLESHOOTING GUIDE
Subsection 05 (ELECTRICAL SYSTEM)
Symptom: REAR LIGHT BULB FLASHES.
1. Check bulb tightness in housing.
- Looseness at bulb contact elements. Install bulb correctly.
2. Check if rear light is properly connected.
- Connector housing is partially connected. Install connector housing properly.
3. Check continuity of wires.
- Corroded terminals and/or broken wires. Replace terminal(s) or crimp defective wires
Symptom: TACHOMETER DOES NOT WORK.
1. Check continuity of wires.
- Corroded terminals and/or broken wires. Replace terminal(s) or crimp defective wires.
Symptom: HIGH BEAM PILOT LAMP LIGHTS UP WHEN LOW BEAM IS SELECTED.
1. Check proper connections.
- YELLOW wire connected to pilot lamp. Mixed-up connections with heating element pilot lamps.
Reconnect a yellow/black wire to pilot lamp. yellow wires are connected to heating element pilot
lamps.
42 mmr2005-008
