Section01MAINTENANCE
Subsection 02 (STORAGE)
STORAGE
SERVICE PRODUCTS
Description Part Number Page
anti-seize lubricant................................................................ 293 800 070 ............................................. 5
BOMBARDIER LUBE ........................................................... 293 600 016
......................................... 3, 5
BOMBARDIER premixed coolant.........................................
293 600 038 ............................................. 5
BOMBARDIER Scratch Remover Kit.................................... 861 774 800 ............................................. 3
fuel stabilizer (250 mL) .........................................................
413 408 600
............................................. 4
Heavy duty cleaner (4 L).......................................................
293 110 002 ............................................. 3
Heavy duty cleaner (spray can 400 g)...................................
293 110 001 ............................................. 3
storage oil (Canada) ..............................................................
413 711 600 ............................................. 4
storage oil (United States) ....................................................
413 711 900
............................................. 4
Vinyl & Plastic Cleaner (6 x 1 L)............................................
413 711 200 ............................................. 3
GENERAL
Proper snowmobile storage is a necessity during
the summer months or when a vehicle is not being
used for more than one month.
Refer to storage column from MAINTENANCE
CHART jointly with the present storage proce-
dure in order to cover each and every aspect of
the snowmobile storage procedure. Any worn,
broken or damaged parts should be replaced.
WARNING
Unless otherwise specified, engine should be
turned off for storage procedure.
VEHICLE CLEANING
To facilitate the inspection and ensure adequate
lubrication of components, it is recommended to
clean the entire vehicle.
Remove any dirt or rust.
To clean the entire vehicle, use only flannel cloths
or equivalent.
CAUTION: It is necessary to use flannel cloths
or equivalent on windshield and hood to avoid
damaging further surfaces to clean.
To clean the entire vehicle, including bottom pan
and metallic parts use Heavy duty cleaner (spray
can 400 g) (P/N 293 110 001) and Heavy duty
cleaner (4 L) (P/N 293 110 002).
CAUTION: Do not use Heavy duty cleaner on
decals or vinyl.
For vinyl and plastic parts, use Vinyl & Plastic
Cleaner(6x1L)(P/N413711200).
To remove scratches on windshield or hood use
BOMBARDIER Scratch Remover Kit (P/N 861 774
800).
CAUTION: Never clean plastic parts or hood
with strong detergent, degreasing agent, paint
thinner, acetone, products containing chlorine,
etc.
Inspect the hood and repair any damage.
Touch up all metal spots with touch-up paint
where paint has been scratched off.
Spray all bare metal parts including shock chromed
rods with BOMBARDIER LUBE (P/N 293 600 016).
Wax the hood and the painted portion of the frame
forbetterprotection.
NOTE: Apply a non-abrasive wax on glossy finish
only.
ENGINE COMPARTMENT
Keep clean of grass, twigs, cloth, etc. These are
combustible under certain conditions.
mmr2005-003 3
