INTRODUCTION
LIST OF ABBREVIATIONS USED
IN THIS MANUAL
ABREVIATION MEANING
A
ampere
amp ampere
A•h ampere-hour
AC alternate current
ACM
acceleration and control modulator
ARM advance ride management
BDC
bottom dead center
BTDC before top dead center
°C degree Celsius
cc
cubic centimeter
CDI
capacitor discharge ignition
CTR
center
cm
centimeter
cm² square centimeter
cm³ cubic centimeter
DC direct current
DPM digital performance management
DSA direct shock action
°F degree Fahrenheit
FC fan cooled
fl. oz fluid ounce
ft foot
GRD
ground
H.A.C. high altitude compensator
hal. halogen
HI high
imp. oz imperial ounce
in inch
in² square inch
in³ cubic inch
k kilo (thousand)
kg kilogram
km/h kilometer per hour
kPa Kilopascal
L liter
lb pound
lbf pound (force)
LH left hand
ABREVIATION MEANING
LO low
LT long track
m
meter
m.
mile
MAG
magneto
Max. maximum
Min. minimum
mL milliliter
mm
millimeter
MPEM multipurpose electronic module
MPH mile per hour
N
newton
N.A. not applicable
no.
number
00.0 continuity
0.L overload (open circuit)
O.D. outside diameter
OPT
optional
oz ounce
P/N part number
PSI pound per square inch
PTO
power take off
R rectangular
RH right hand
RAVE rotax adjustable variable exhaust
RPM revolution per minute
RMS
root mean square
RRIM
reinforced reaction injection
molding
Sp. Gr.
specific gravity
ST semi-trapezoidal
TDC
top dead center
TRA total range adjustable
U.S. oz ounce (United States)
V volt
Vac volt (alternative current)
mmr2005-001 XVII
