Section 02 TROUBLESHOOTING GUIDE
Subsection 02 (ENGINE (4-TEC))
Symptom: STARTER DOES NOT TURN. (contd)
3. Check 30 A and 5 A fuses.
- Burnt fuse. Check wiring condition and replace fuse.
4. Check continuity of starter switch contact points.
- Poor contact of starter switch contact points. Repair or replace switch.
5. Check continuity between starter switch and ECM.
- Open circuit. Repair.
6. Check continuity between ECM and solenoid switch.
- Open circuit. Repair.
Symptom: STARTER TURNS, BUT ENGINE DOES NOT CRANK.
1. Check the starter gear.
- Starter gear and/or intermediate gear is worn or damaged. Replace starter gear and/or interme-
diate gear (refer to CRANKSHAFT/DRIVE GEARS).
2. Check the sprag clutch.
- Sprag clutch is worn or otherwise damaged. Replace sprag clutch (refer to CRANKSHAFT/DRIVE
GEARS).
Symptom: STARTER TURNS SLOWLY
1. Check battery capacity.
- Shorted battery cell(s). Replace.
2. Check battery charge.
- Low battery. Recharge battery and check recharge system and wires.
3. Check wire connection.
- Inadequate connection (too much resistance). Clean and reconnect.
4. Check brushes.
- Poor contact of brushes. Replace starter.
5. Check commutator.
- Burnt commutator. Replace starter.
6. Check engine.
- Engine seized. Overhaul the engine.
7. Check field coil resistance.
- Shorted field coil. Replace starter.
8. Check armature resistance.
- Shorted armature. Replace starter.
9. Check tension of brush springs.
- Weak brush spring tension. Replace starter.
10. Check if bushings are worn.
- Worn bushings. Replace starter.
20 mmr2005-020
