Section11BODY/FRAME
Subsection 01 (BODY)
CABLES
WARNING
Before installation, ensure that all cables are
in perfect condition. Properly install the cable
ends and secure them in place. Pay attention
to route them properly, away from any rotat-
ing, moving, heating or vibrating parts.
TUBING
WARNING
Always ensure that the fuel, vent, primer, im-
pulse, injection oil and rotary valve oil lines
are properly fixed to their connectors, that
they are not perforated or kinked and that
they are properly routed away from any rotat-
ing, moving, heating or vibrating parts. Also
check for leaks. Replace if required.
NOTE: Refer to proper Parts Catalog to find suit-
able clip part numbers.
PLASTIC MAINTENANCE
AND REPAIR
MAINTENANCE
Clean the vehicle thoroughly, removing all dirt and
grease accumulation.
To clean use a soft clean cloth and either soapy
water or isopropyl alcohol.
To remove grease, oil or glue use isopropyl alco-
hol.
CAUTION: Do not apply isopropyl alcohol or
acetone directly on decals.
CAUTION: The following products must not be
used to clean or wax any of the plastic compo-
nents used on the vehicles:
– gasoline
– brake fluid
– kerosene
– diesel fuel
– lighter fluid
– varsol
– naphtha
– acetone
– strong detergents
– abrasive cleaners
– waxes containing an abrasive or a cleaning
agent in their formula.
Apply wax on glossy finish only. Protect the ve-
hicle with a cover to prevent dust accumulation
during storage.
CAUTION: If for some reason the snowmobile
has to be stored outside, it is preferable to cov-
er it with an opaque tarpaulin. This will prevent
the sun rays from affecting the plastic compo-
nents and the vehicle finish.
REPAIR
The very first step before repairing plastic materi-
als is to find out exactly which type of material is
involved.
CAUTION: Some repair products are not com-
patible with certain plastics.
WARNING
Polycarbonate windshields must never be re-
paired by welding or otherwise.
For hood repair, refer to a specialized shop.
The following company provides a complete line
of products to repair plastic materials:
CREST INDUSTRIES, INC.
TRENTON, MI 48183
PHONE: (734) 479-4141
TOLL FREE: 1 800 822-4100
FAX: 734-479-4040
E-MAIL: INFO@CRESTAUTO.COM
WWW.CRESTAUTO.COM
462 mmr2005-099
