Section 05 ENGINE MANAGEMENT (POWER TEK)
Subsection 02 (DIAGNOSTIC PROCEDURES)
Fault code P1102 (TPS “OutofRange” Fault)
It is caused by the sensor reading going out of its allowable range. This fault can occur during the whole
range of movement of the throttle.
To diagnose this fully, it is recommended to operate the throttle through its full range. It is also recom-
mended to release the throttle quickly as this may also reveal a fault that is intermittent.
POSSIBLE CAUSES ACTION
Check if connector is disconnected from TPS Reconnect.
Check if sensor is loose Tighten sensor and reset
Closed Throttle
.
Inspect sensor for damage or corrosion
Replace sensor and reset
Closed Throttle
.
Inspect wiring (voltage test) Repair.
Inspect wiring and sensor (resistance test)
If bad wiring, repair.
If bad TPS, replace and reset
Closed Throttle
.
Test sensor operation (wear test) Replace sensor and reset
Closed Throttle
.
Fault code P1104 (TPS “Adaptation Failure” Fault)
It is caused by the idle position moving out of an acceptable range.
Following problems can be caused by a TPS “Adaption Failure“:
– Idle speed is out of range.
– Engine stops, when throttle is released quickly.
– Engine runs inconsistent in low partload or low RPM.
POSSIBLE CAUSES ACTION
Sensor has been replaced and TPS closed
position not reset
Reset
Closed Throttle
.
Carburetor has been replaced and TPS closed
position not reset
Reset
Closed Throttle
.
EMS has been replaced and TPS closed
position not reset
Reset
Closed Throttle
.
Throttle cable too tight Adjust cable and reset
Closed Throttle
.
Sensor is loose Tighten sensor and reset
Closed Throttle
.
Throttle bracket is loose
Fix and reset
Closed Throttle
.
mmr2005-106 207
