Section01MAINTENANCE
Subsection 01 (MAINTENANCE CHART)
MAINTENANCE CHART
10-HOUR OR 500 KM (300 mi) INSPECTION (to be performed by dealer)
A: ADJUST
WEEKLY OR EVERY 240 KM (150 mi)
I:
INSPECT (clean, inspect, repair, adjust, lubricate)
MONTHLYOREVERY800KM(500mi)
L: LUBRICATE
ONCE A YEAR OR EVERY 3200 KM (2000 mi)
R: REPLACE
6000 KM (3700 mi)
C: CLEAN
STORAGE (to be performed by dealer)
PRESEASON PREPARATION
(to be performed by dealer)
PART/TASK
REFER TO SECTION(S) AND
SUBSECTION(S)
ENGINE
Rewind starter and rope
I,L,C
I 03-09
Engine nuts and screws I I I
Section 03 or 04, see the
appropriate subsection
Exhaust system I I I
Section 03 or 04, see the
appropriate subsection
Engine lubrication L
01-02
Cooling system I I I 03-08 or 04-03
Coolant I R
03-08 or 04-03
Condition of seals
(4)
I I 03-01, 03-02, 03-03 or 04-02 to 04–07
RAVE valves
(4)
C
03-03
LUBRICATION
Oil and filter replacement (4-TEC) R
04-04
Injection oil filter I R 03-06
Oil injection pump A A A
03-06
FUEL
Fuel stabilizer R
01-02
Fuel filter R 01-03
Fuel lines and connections I I I
03-10, 06-03 or 05-03
Carburetor A A
A,C
03-10
Throttle cable I I I I
03-10
Air filter
C C
01-03
Fuel injection system (visual inspection) I
05-03 or 06-03
Throttle body bores and throttle plates
(4)
C
05-03 or 06-03
DRIVE
Drive belt I I I 07-01
Drive and driven pulley I I C I C 07-02 and 07-03
Tightening torque of drive pulley screw I I I 07-02
Driven pulley preload I I I
07-03
BRAKE
Brake fluid I I R I
07-05
Brake I I A I,A I 07-05
mmr2005-002 1
