Section 12 TECHNICAL DATA
Subsection 02 (LIQUID COOLED MODELS)
LIQUID COOLED MODELS
GSX/GTX/MX Z GSX/GTX/MX Z/SUMMIT
MODEL
500 SS 600 HO 800 HO
ENGINE
Engine type 593 593 HO 793 HO
Number of cylinder 2
Bore Standard mm (in) 76 (2.992) 72 (2.835) 82 (3.228)
Stroke mm (in) 65.80 (2.591) 73 (2.874) 75.70 (2.980)
Displacement cm
3
(in
3
) 597.00 (36.431) 594.40 (36.273) 799.50 (48.789)
Compression ratio 12.00 ± 0.5 12.25 ± 0.5 12.00 ± 0.5
593/593 HO/793 HO 8000 ± 100 RPM 7850 ± 100 RPM
Maximum power engine speed (1)
793 HO Power TEK N.A. N.A. 7950± 100 RPM
1
st
Semi-trapezoidal
Piston ring type
2
nd
—
New mm (in) 0.40 to 0.55 (.016 to .022)
Ring end gap
Wear limit mm (in) 1.0 (.039)
New mm (in) 0.04 to 0.09 (.0016 to .0035) 0.05 to 0.1 (.0020 to .0039)
Ring/piston groove clearance
Wear limit mm (in) 0.2 (.0079)
Piston/cylinder wall clearance New
mm
(in)
0.120 ± 0.016
(.0047 ± .0006)
0.105 ± 0.013
(.0041 ± .0005)
0.125 ± 0.022
(.0049 ± .0009)
Wear limit mm (in) 0.20 (.0079) 0.18 (.0071) 0.20 (.0079)
Maximum crankshaft end play (2) New mm (in) 0.3 (.012)
Maximum crankshaft deflection at PTO Wear limit mm (in) 0.06 (.0024)
Connecting rod big end axial play New
mm
(in)
0.390 to 0.737
(.0154 to .0290)
0.310 to 0.677
(.0122 to .0267)
Wear limit mm (in) 1.2 (.0472)
ELECTRICAL
Magneto generator output 360 W
Ignition type CDI
Make and type NGK BR9ECS (6)
Spark plug
Gap mm (in) 0.40 to 0.50 (.016 to .020)
Ignition timing BTDC (3) (7) mm (in) 2.49 (.0980) 2.79 (.110) 2.37 (.0933)
Trigger coil (4) 190 to 300
Low speed —
Generating coil (4)
High speed —
Lighting coil (4) 0.1 to 1.0
Primary —
High tension coil (4)
Secondary —
mmr2005-101 471
