Section 03 ENGINES
Subsection 03 (ENGINE REMOVAL AND INSTALLATION)
REMOVAL FROM VEHICLE
Vehicle and Engine Preparation
Place vehicle at workstation that will have access
to an engine-lifting hoist. Then start with initial
preparation of vehicle by doing the following.
Remove windshield.
RemovetheRHsidepanel.
Disconnect BLACK (-) cable from battery, then the
RED (+) cable.
WARNING
Always disconnect battery or starter cables
exactly in the specified order, BLACK (-) cable
first. It is recommended to disconnect elec-
trical connections prior to disconnecting fuel
lines.
On SDI models, release the fuel pressure of the
system. Refer to COMPONENT INSPECTION
AND ADJUSTMENT.
From the Front of Vehicle
Remove tuned pipe and manifold, refer to EX-
HAUST SYSTEM.
A33C26A
Remove starter.
NOTE: Remove BLACK starter cable from vehicle,
not from starter.
On right side of vehicle, do the following:
Remove muffler.
Drain coolant reservoir.
Unplug from the coolant reservoir the hose going
to the engine.
A33C27A
1
1. Coolant hose between reservoir and engine
Usingpump(P/N529035880),drainmaximum
coolant from hose and engine.
529 035 880
mmr2005-070 65
