Section 12 TECHNICAL DATA
Subsection 01 (ENGINES)
SKANDIC EXPEDITION TUV V-1000
ENGINE TYPE
1004
ENGINE (cont'd)
Connecting rod big end diameter Wear limit mm (in) 45.090 (1.7752)
Connecting rod big end clearance Wear limit mm (in) 0.09 (.0035)
New mm (in) 0.150 - 0.450 (.0059 - .0177)
Connecting rod big end axial play
Wear limit mm (in) 0.500 (.0197)
New mm (in) 23.010 - 23.020 (.9059 - 9063)
Connecting rod small end diameter
Wear limit mm (in) 23.070 (.9080)
New mm (in) 22.996 - 23.000 (.9053 - .9055)
Piston pin diameter
Wear limit mm (in) 22.990 (.9051)
Piston pin bore clearance Wear limit mm (in) 0.080 (.0031)
ELECTRICAL
Alternator output V, A 12, 40
Ignition system type DI (Digital Induction)
Ignition timing Not adjustable
Make and type NGK DCPR8E
Spark plug
Gap mm (in) 0.75 (.030)
Primary .85 - 1.15
Ignition coil
Secondary k 9.2 - 13.8
Engine RPM limiter setting RPM 8000
FUEL SYSTEM
Fuel injection type
ROTAX EMS (Engine Management System) Multipoint
Fuel Injection, Single throttle body (52 mm)
Fuel pressure
kPa
(PSI)
400 (58)
Idle speed RPM 1400 ± 100
Throttle Position Sensor (TPS)
(4)
k 1.6 - 2.4
Crankshaft Position Sensor (CPS)
(4)
.7 - 1.1
Camshaft Position Sensor (CAPS) V 12
Camshaft Position Sensor (CAPS)
(4)
k 1.2
Air Temperature Sensor (ATS)
(4)
k 2.28 - 2.74
Coolant Temperature Sensor (CTS)
(4)
k 2.28 - 2.74
Manifold Air Pressure Sensor (MAPS) V 5
Idle bypass valve
(4)
50
Oil Pressure Switch (OPS)
(4)
0 (continuity), if oil pressure is lower than 20 kPa (2.9 PSI)
Fuel injector 13.8 - 15.2
Type Regular unleaded
Fuel
Octane
North America: 87 (R+M)/2
Elsewhere: 91 RON
mmr2005-057 557
