Section01MAINTENANCE
Subsection 02 (STORAGE)
STORAGE
SERVICE TOOLS
Description Part Number Page
cleat remover........................................................................ 529 028 700 .............................................5
narrow-cleat installer ............................................................ 529 028 800 .............................................5
SERVICE PRODUCTS
Description Part Number Page
anti-seize lubricant................................................................ 293 800 070 ............................................. 5
BOMBARDIER LUBE ........................................................... 293 600 016
.........................................4, 6
BOMBARDIER scratch remover kit ..................................... 861 774 800 .............................................6
fuel stabilizer......................................................................... 413 408 600 ............................................. 4
heavy duty cleaner (4 L)........................................................
293 110 002 ............................................. 6
heavy duty cleaner (spray can 400 g) ...................................
293 110 001 ............................................. 6
storage oil (Canada) ..............................................................
413 711 600 ............................................. 4
storage oil (USA)...................................................................
413 711 900 ............................................. 4
suspension synthetic grease................................................
293 550 033 ............................................. 5
vinyl & plastic cleaner (6 x 1 L) .............................................
413 711 200 ............................................. 6
GENERAL
Proper snowmobile storage is a necessity during
the summer months or when a vehicle is not being
used for more than one month.
Refer to storage column from MAINTENANCE
CHART jointly with the present storage proce-
dure in order to cover each and every aspect of
the snowmobile storage procedure. Any worn,
broken or damaged parts should be replaced.
WARNING
Unless otherwise specified, engine should be
turned off for storage procedure.
ENGINE
Rewind Starter and Rope
For inspection, cleaning and lubrication, refer to
ENGINE section.
Engine Motor Mounts
Check if engine support is cracked, bent or other-
wise damaged. Replace if necessary.
Check rubber mounts on engine support. Replace
them if brittle, cracked or otherwise damaged.
Exhaust System
Check and replace if necessary:
– tuned pipe shield for damages
– tuned pipe ends for cracks or damages
– manifold for cracks or damages.
Engine Lubrication
NOTE: Be sure to add fuel stabilizer before start-
ing the engine.
Engine internal parts must be lubricated to protect
them from possible rust formation during the stor-
age period.
mmr2005-061 3
